Experimental Hydrofoil Model

In these images the hydrofoil apparatuses are mounted on a Sunfish hull for testing purposes. In the left-most image the starboard hydrofoil is set for negative lift and the port one for positive lift.  These are the normal position for moderate and heavy breezes while on starboard tack.
